Automotive Quick Connector OF 9.49mm --ID12.5mm
Item:fuel line quick connector 9.49mm to hose ID 12.5mm,elbow
Item number:D15
with O-ring on fir tree
Size:Ø9.49mm-- ID 12.5mm
Hose fitted:ID x OD 12.5x15.5mm only
Material:PA12+30%GF
Media:Fuel line,Gasoline,diesel
Color:Black with grey locking spring
MOQ:Any quantities to start business

FAW China,JAC China,Dongfeng China,Hutchinson Wuhai,KONGSBERG Wuhai.
Export:Dorman USA,DYTECH,Sichuan Ring Technology,... aftermarket in IRAN,INDIA,CHILE,ITALY,MALAYSIA,TURKEY,EGYPT,BRAZIL....

Yongheng connectors Advantages:
1.we improved the locking spring design,the little change can avoid installation error for any of operators who have little experience doing this job.
 This little change will increase pull-apart effort when mating male end-piece.


2.We improved the injection molds to add O-ring on fir tree,which will increase the safety capability when install to nylon hose.


 * Fast assembly without tool  time and cost reduction

* Robot assembly possible  automated processes

 * Integrated seal  optimal tightness

* Compact building method  employment in extremely close installation conditions possible

* Helps meeting environmental requirements


Quick connector working environment:
a. Gasoline and diesel fuel delivery systems,Ethanol and methanol delivery system or their vapor venting or evaporative emission control systems.
b. Operating pressure 500kPa,5bar,(72 psig)
c. Operating vacuum -50kPa,-0.55bar(-7.2psig)
d. Operating temperature -40(-40) to 115 (239),short time 150

YONGHENG PATENT NUMBER
201110107011.6
